Copper Flashings and Weatherings - A Practical Handbook

COPPER FLASHINGS AND WEATHERINGS A PRACTICAL HANDBOOK Copper domes, Westminster Cathedral, London CONTENTS FOREWORD . . . . . . . . . . . . . . . . . . . . page 6 INTRODUCTION . . . . . . . . . . . . . . . . . . Advantages of using copper long life, ease of fixing, economy-Relative expansion of copper-Expansion joints-Saving in weight-Avoided by boring insects CHAPTER I. GENERAL NOTES ON COPPER SHEET AND STRIP . . 9 Physical properties of copper, lead and zinc compared-Work-hardening of copper-Annealing copper-Thicknesses employed---Sheet and Strip defined --Hints on ordering sizes--Temper preferred CHAPTER 11. JOINTS, DAMP-PROOF COURSES, FLASHINGS .... 11 Joints-Standing seams-Single and double lock welts-Wood rolls-Welding- Avoidance of solder-Nails and screws-Roofing felt-Securing to brickwork - Gutters and drips-Cleats-Spacing of cleats--Damp-proof courses-Not attacked by ordinary cement or mortar-Cavity and through wall flashings CHAPTER 111. OTHER USES OF COPPER SHEET AND STRIP IN BUILDING . . . . . . . . . . . . . . . . . . . . 14 Copper rain-water goods advantages over iron-Avoiding electrolytic action- Working copper sheet for rain-water goods-Suitable temper-Stiffening of gutters - Spacers -Expansion - Copper lightning conductors. SOME NOTABLE BUILDINGS EMBODYING COPPER FOR WEATHERING PURPOSES . . . . . . . . . . . . . . 17 SUMMARY OF DETAILED DRAWINGS . . . . . . . . . . . . 18 TOOLS . . . . . . . . . . . . . . . . . . . . . . .U DETAILS OF FINISHINGS AND WEATHERING, ROLIS, GUTTERS, EXPANSION JOINTS, ETC. . . . . . . . . . . . . . . -- .P WEIGIIIS OF COPPER STRIP AND SEALS . . . . . . . . . . 129 LIST OF AVAILABLE C.D.A. PUBLICATIONS . . . . . . . . 130 FOREWORD This handbook has been compiled to give essentially practical details of the manner in which copper sheet and strip are used for flashings and weatherings of all normal types. It is intended especially for those who actually have to carry out the work, though it will, no doubt, also be of interest to thosc concerned with design or specification. In carrying out such flashings and weatherings to buildings the craftsman may come across certain individual problems not illustrated in the following pages, but it is hoped that by studying the methods shown a satisfactory solution to the problem will be found. However, if some point arises that is not covered by the foregoing remarks, the Copper Development Association would welconle the opportunity to advise the reader on the best methods to be used. In dealing with copper sheet or strip it must be realised that whilc the technique to be employed calls for no special skill or training, it is important that a little extra care and forethought should be given to setting out the work this will amply repay the craftsman, and a knowledge of the physical properties of thc metal will enable him to produce work equal to that of the old craftsmen whose efforts were renowned. The aim of the sheet copper worker must be to achieve the necessary shape or form with as little actual working of the metal as possible. Thus it will be seen that the working technique of other metals is not always applicable. Since the first appearance of this book in 1947, a Supplement containing 14 pages of additional details has been issued and distributed to recipients of thc first edition. This extra matter has been incorporated in the present edition. Radlett, DEC., l951 COPPER DEELOPMENT ASSOCIATION INTRODUCTION Although this is intended to be a practical handbook, mainly to be used by the man carrying out work to others instructions, it is nevertheless appropriate to consider briefly the reasons why copper is specified for use in making a building watertight. The reasons are not hard to find, and are bascd upon the behaviour of the metal through hundreds of years of practical experience...
